6-Seater Lifted Golf Cart
Model code KC-G4+2H · KR-G4+2H — Signature / Adventure
The 6-Seater Lifted Golf Cart is a 4+2 electric golf cart — 4 forward-facing seats and a rear-facing flip seat for 2 — on a purpose-built 6-seat frame with a 2,420 mm wheelbase and a lifted chassis with 190 mm of minimum ground clearance. It is built with rear-wheel drive or a part-time 4x4, on a 48V 5 kW AC drivetrain and LiFePO4 battery.
Best for resorts, ranches and large properties moving groups over rough ground — the capacity end of your off-road line, on the purpose-built 6-seat frame.
Related builds: Standard · Premium · Premium · Lifted
Configure your 6-Seater Lifted Golf Cart
Configure your build, then add it to your quote — we usually reply within one business day.
Standard equipmentStandard
Included in every build — the comfort, convenience & safety features other dealers upsell.
Appearance packagetwo front-end styles — choose one
Body colorAll 12 standard colors · dot = render on request
Selected: Sapphire Blue
Wheels & tiresSize follows the package & chassis
Standard 12" alloy · all-terrain tires, DOT-certified tires.
Seat leatherOur standard leathers · tap to preview · + = custom (other color / two-tone / stitching)
Selected leather: 318 Black. Integrally foam-molded cushions + premium microfiber leather. A different color, two-tone or stitching is available as a custom order.
Everything below is optional. Your cart already ships with everything in the standard equipment list — nothing here needs ticking to get a complete quote.
Range & drive5▾
Battery / range
Sound & light5▾
Comfort & cabin2▾
Weather protection3▾
On-course extras4▾
Make it yours7▾
Dashboard finishwater-transfer film · priced in your quote
No prices shown here. After you add to the quote, we usually reply within one business day.
A Part-Time 4×4 With a Hand-Engaged Mechanical Differential Lock
This is a part-time 4×4 with two switches: one locks into four-wheel drive, one engages a mechanical differential lock that keeps torque on the wheels with grip. The driver engages both before the terrain, not after a wheel is already spinning. Every 4×4 also leaves the line with a front winch, so a cable to an anchor point recovers the cart without waiting for a tow. A dealer can show both switches and the winch anchor point on the lot.
How This Model Earns Its Slot in Your Lineup
Choose this lifted 6-seater if… your resort, ranch or rental buyers move five or six people off pavement — it's the only six-seat off-road option in the line.
The verified difference. The purpose-built 6-seat frame on its own 2,420 mm wheelbase — not a stretched 4-seater — on the 190 mm lifted chassis, with a part-time 4×4 and hand-engaged mechanical differential lock.
Specifications
Image stays pinned · spec groups switch as you scroll.
Powertrain
- Motor
- 48V 5KW IP67 AC motor
- Controller
- 48V-350A IP67 AC controller, with CAN communication + Bluetooth
- Battery
- 51.2V 105Ah LiFePO4 (UN38.3, MSDS documented) — 150Ah / 73.6V / lead-acid optional
- Charger
- 48V/25A onboard smart charger, ≤5 h charge time
- DC-DC
- High-power non-isolated DC-DC 48V/12V-300W
- Top Speed
- ≤25 mph (governed to your market)
- Range (flat road)
- 37–50 miles (60–80 km)
- Climb / Hold Grade
- 20% / 20%
Chassis & Suspension
- Seating
- 6 — 4+2 (4 forward + 2 rear-facing)
- Chassis
- High-strength steel one-piece bent main beam + composite frame; process: acid-pickling + electrophoresis + paint (pillars: pickling + electrophoresis + powder coat)
- Front Suspension
- MacPherson independent + coil spring + tubular hydraulic shock
- Rear Suspension
- Integral rear axle (ratio 12.3:1) + coil spring + tubular hydraulic shock + H-arm + anti-roll bar
- Steering
- Bi-directional rack & pinion with automatic clearance compensation (EPS optional)
- Curb Weight (w/o battery)
- ≤555 kg (without battery)
- Dimensions (L×W×H)
- 3680 × 1330 × 2040 mm
- Track / Wheelbase
- Front/rear track 1030 / 1030 mm; wheelbase 2420 mm
- Turning Radius
- 5 m
- Ground Clearance
- 140 mm standard / 190 mm lifted (H)
- Wheels / Tires
- Signature: 10" alloy 186-10INCH (lifted 12" + P334 all-terrain), DOT WG02 road 205/50-10 (4 Ply Rated). Adventure: 14" alloy 550, DOT WR028 road 215/35-14 / WG03 all-terrain
Braking & Safety
- Braking
- Four-wheel hydraulic + four-wheel disc brakes + 58 N·m electromagnetic parking brake (with vehicle hold/traction)
- Lighting
- LED front combination lamp (low/high beam, turn, DRL, position) + LED tail lamp (brake, position, turn)
- Braking Distance
- <4 m
Comfort & Tech
- Body
- Injection-molded exterior, metallic automotive-grade paint; injection-molded matte-black canopy
- Floor
- One-piece anti-aging floor mat
- Seats
- Integrally foam-molded cushions + premium microfiber leather; embossed (striped)
- Instrument / Multimedia
- IP66 10" multimedia cluster; CarPlay + Android Auto, Bluetooth, Radio, Music, Type-C charging + USB, reversing camera
- Audio
- IP66 full-range 5" coaxial hi-fi speaker H-505 (upgradable to 6.5" H065B sound-reactive lighting / 8-channel soundbar)
- MOQ
- First custom order: 1 branded sample. Repeat orders by the container — mix models & trims
Specs shown are the full factory standard configuration for the Signature (KC) package. Top speed is governed to your market; battery, lift, drivetrain, package and options change some values — full datasheet available on request.
See how lift and 4x4 options work across the lifted and 4x4 golf cart range.
6-Seater Lifted Golf Cart FAQ
Do all 6 seats face forward?
No. This is a 4+2: 4 forward-facing seats and a rear-facing flip seat for 2. If every passenger needs to face forward, the 6-Seater Lifted Premium seats 6 in 3 forward-facing rows on the same lifted chassis with 190 mm of minimum ground clearance.
See the 6-Seater Lifted Premium Golf Cart.
Is the 6-seater a stretched 4-seater?
No. It uses a purpose-built 6-seat frame on its own 2,420 mm wheelbase, with a 5 m turning radius.
Can I get the 6-seater as a 4x4?
Yes. The lifted chassis is built with rear-wheel drive or a part-time 4x4 with a hand-engaged mechanical differential lock, and every 4x4 build comes with a front winch as standard.
How far does it go on a charge?
37–50 miles (60–80 km) on flat road from the standard 51.2V 105Ah LiFePO4 battery. The standard configuration lists an onboard 48V/25A charger and a charge time of 5 hours or less; a 150Ah battery is optional. Top speed is up to 25 mph, governed to your market. Battery, lift and drivetrain choices change some of these values.
Is it street legal?
We make no claim about public-road use. The windshield and seat belts are DOT-certified components, but DOT components do not make a street-legal vehicle; ride height and drivetrain do not establish LSV status either. Road access depends on the complete vehicle and the rules where it is used.
See our street-legal golf cart and LSV guide.
Can I order one under my own brand?
Yes. A dealer's first private-label order can be a single branded sample, and repeat orders ship by the container with models and trims mixed. Private-label options include custom paint, a laser-etched lit grille logo, seat logo embroidery and a custom start-up animation. Most orders take about 45 working days after deposit and artwork approval; a new mold or a special process is quoted per project.
See every private-label and customization option.
What warranty comes with it?
15 months on the vehicle and 3 years on the lithium battery. Wear items such as tires and upholstery are not covered.
